RAD TORQUE TOOLS & ACCESSORIES
Global Mining Products Inc. (877) 576-2855

Pneumatic Torque Systems
[ view standard version ]
RAD-4000 Pneumatic Torque Wrench
The RAD 4000 pneumatic torque wrench has been our flagship tool for several years. The RAD 4000 is being used for heavy to super duty applications in virtually every industry worldwide. The RAD 4000 replaces 1.5" impact wrenches and hydraulic torque wrenches

RAD Torque Tool
  • PATENTED planetary gear reduction drive system delivering one of the highest power-to-weight ratios of any pneumatic controlled bolting system

  • Smooth continuous flow of controlled torque eliminating destructive hammering
  • Lightweight ergonomic pistol grip design reducing operator strain and injury; resulting in increased productivity

  • Controlled torque – accuracy of +/-5%, and repeatability of +/-2%

RAD 4000 Classic Series
Part No.
Drive Size
Torque
(Low- High)
RPM
Weight (kgs)
Noise Level
RAD-13567
1.0"
1400-4050 Nm
14
9.2
85 db

All RAD 4000 Classic Series Torque Tools come fully calibrated complete with:
Torque Tools


• RAD 4000 Torque Tool
• Standard Reaction Arm and Retention Ring
• 12" Hose & Fittings
• Ergonomic Regulator Cage and Tool Holder
• Operators Manual and CD
• Calibration Chart

To ensure the highest quality of measurement and accuracy, each RAD® pneumatic tool comes individually calibrated traceable to NIST standards.
Reaction Arms for RAD 4000
Torque Tool Reaction Arm
Torque Tool Reaction Arm
Torque Tool Reaction Arm
Torque Tool Reaction Arm
Torque Tool Reaction Arm
Standard
Deep Socket
Double Ended
Blank
Double Ended Blank
RAD-10022
RAD-10025
RAD-10027
RAD-10024
RAD-10026
***Reaction arms not exactly as shown.

Global Mining Products offers a variety of accessories and custom reaction arms to ensure our tools are achieving 100% of their performance. Please contact us at 877-576-2855 if you have a specific or custom application. We can design asolution to meet your needs.
