RAD-1100NG Pneumatic Torque Wrench
The RAD 1100NG pneumatic torque wrench is a very popular tool for a variety of medium duty applications. The versatility and reliability of the Next Generation gearboxes, coupled with a broad torque range and small profile, are solving hundreds of bolting problems worldwide.

RAD Torque Tool
  • PATENTED planetary gear reduction drive system delivering one of the highest power-to-weight ratios of any pneumatic controlled bolting system

  • Smooth continuous flow of controlled torque eliminating destructive hammering
  • Lightweight ergonomic pistol grip design reducing operator strain and injury; resulting in increased productivity

  • Controlled torque – accuracy of +/-5%, and repeatability of +/-2%

RAD 1100NG Classic Series
Part No.
Drive Size
Torque
(Low- High)
RPM
Weight (kgs)
Noise Level
RAD-13543
0.75"
200-1100 Nm
30
4.3
85 db

All RAD 1100NG Classic Series Torque Tools come fully calibrated complete with:
Torque Tools


• RAD 1100NG Torque Tool
• Standard Reaction Arm and Retention Ring
• 12" Hose & Fittings
• Ergonomic Regulator Cage and Tool Holder
• Operators Manual and CD
• Calibration Chart

To ensure the highest quality of measurement and accuracy, each RAD® pneumatic tool comes individually calibrated traceable to NIST standards.
Reaction Arms for RAD 1100NG
Torque Tool Reaction Arm
Torque Tool Reaction Arm
Torque Tool Reaction Arm
Torque Tool Reaction Arm
Torque Tool Reaction Arm
Standard
Deep Socket
Double Ended
Blank
Double Ended Blank
RAD-10043
RAD-10458
RAD-10459
RAD-10044
RAD-10045
***Reaction arms not exactly as shown.

Global Mining Products offers a variety of accessories and custom reaction arms to ensure our tools are achieving 100% of their performance. Please contact us at 877-576-2855 if you have a specific or custom application. We can design asolution to meet your needs.
